Pipe direct connection style stainless steel filter housing for industry pipe
Description
Packaged design brings so many using advantage of this filter housing, it is wilding used line testing point, pipe connection point, etc. small flow application point. While it is a very economic choice for some SMEs.
Specification
Table 1, Surface Treatment
| Polishing Type | Physical / Electro |
| Polishing Rating | I-0.3μm / O-0.4μm |
Table 2, Operational Environment
| Pressure | 0.6Mpa (6bar) |
| Max Temp. | 130℃ (266℉) |
| Sterilization | 121℃/30Min. |
Table 3, Material
| Housing | 304, 316L |
| Vent/Drain Valve | 304, 316L |
| Tri-Clasp | 304 |
| O-ring/Gasket | Silicone, Viton, EPDM, PTFE |
Table 4, Connection
| Cylinder | Flange, Quick coupler |
| Inlet/outlet | 38mm Quick coupler |
| Vent | Normal gas valve |
| Drain | Normal liquid valve |
Feature & Benefits
Ordering Information
|
|
