316 L small flow disc stainless steel filter housing for lab use
Description
U-DMF membrane filter housing is designed and made according to sanitary grade, easy to disassemble and cleaning, polishing rating is as high as 0.3 micron, totally meet the demand of GMP.
One or two layers of membrane can be put inside, ideal structure to seal liquid, easy to operation, wildly used in lab, can meet small flow filtration either.
Specification
| Polishing | Type | Physical & Chemical |
| Precision | In-0.3μm,Out-0.4μm | |
| Material | Shell | 304, 316L |
| Inlet & outlet, valve | 304, 316L | |
| Clasp | 304 | |
| Stand bar | 304 | |
| Sealing ring & gasket | Silicone, Viton, EPDM | |
| Connect | Barrel | Counterthread screw |
| Inlet and outlet | Quick coupler | |
| Valve | ID4mm with 8mm tube | |
| Work Condition | Max. Work Pressure | 0.6Mpa (6Bar) |
| Work Temp. | 90℃ / Max140℃ | |
| Sterilization | 121℃/30Min |
Application
Pharmaceutical and food lab, other small flow filtration.
Feature & Benefits
1, Sanitary grade polishing, electropolishing acceptable
2, Structure can be disassembled, easy to cleaning
3, Two layers membranes can be installed, wide application
Ordering Information
|
|
