| Brand Name : | UPK |
| Model Number : | U-SS006 |
| Certification : | CE |
| Price : | Negotiation |
| Payment Terms : | L/C, T/T, PAYPAL |
| Supply Ability : | 200 PCS PER MONTH |
| Delivery Time : | 20-30DAYS |
Suctorial tyle 304 stainless steel filter housing for industry use
Specification
| Flow Rate | 25-1200m3/h |
| Min. Working Pressure | 0.1Mpa |
| Max. Working Pressure | 1.0Mpa / 1.6Mpa / 2.5Mpa |
| Pressure Loss ( In Washing ) | 0.01Mpa |
| Max. Working Water Temp. | 80℃ |
| Filtration Precision | 50-3500micron |
| Automatic Washing Time | 60 seconds |
| Auto Washing Control | Differencitial, time and automatic |
| Voltage | 220V |
| Operation Rated Voltage | 220V 380V 50HZ |
Model Selection
| Model | Pipe φ | Flow Rate | Filtration Area | Drain Outlet φ | Water Volume (1 time washing) | Power of Motor | Weight |
| UPK-50XF | 50 | 20 | 1500 | 50 | 75 | 0.55 | 85 |
| UPK-80XF | 80 | 50 | 1500 | 50 | 75 | 0.55 | 87 |
| UPK-100XF | 100 | 80 | 3000 | 50 | 150 | 0.55 | 210 |
| UPK-125XF | 125 | 100 | 3000 | 50 | 150 | 0.55 | 212 |
| UPK-150XF | 150 | 150 | 7000 | 50 | 150 | 0.55 | 212 |
| UPK-200XF | 200 | 300 | 7000 | 50 | 150 | 0.55 | 220 |
| UPK-250XF | 250 | 450 | 11000 | 80 | 400 | 0.55 | 395 |
| UPK-300XF | 300 | 600 | 11000 | 80 | 400 | 0.55 | 405 |
| UPK-350XF | 350 | 900 | 13500 | 80 | 400 | 0.55 | 625 |
| Max Water Temp. | 60℃ (Reach 100℃ for some special demand | ||||||
| Backwash Time | 50-90 seconds | ||||||
| Backwash Water Volume | 280-310kg | ||||||
| Electric Power | 380V, 50HZ, Controller 220V | ||||||
| Motor Power | 0.37Kw Absorbing Mouth Type | ||||||
| Filter Housing Shell | Resin coating on surface | ||||||
| Filtering Net | Stainless steel multi-layer net, screen and PVC frame | ||||||
| Drain Valve | Resin coating on iron surface | ||||||
|
|
